RAG Chat App

Prerequisites

2. Create the Lakebase Postgres prerequisites

The template's AppKit Lakebase plugin requires an existing Postgres branch and database. databricks postgres create-project automatically provisions a default branch named production and a default database on it, so one command is all you need. Pick a short lowercase project id and export the resolved resource names — the next step's databricks apps init command reads them as shell variables.

PROJECT_ID=rag-chat

databricks postgres create-project "$PROJECT_ID"

export BRANCH_NAME="projects/$PROJECT_ID/branches/production"
export DATABASE_NAME=$(databricks api get "/api/2.0/postgres/$BRANCH_NAME/databases" -o json | \
  python3 -c "import json,sys; print(json.load(sys.stdin)['databases'][0]['name'])")

echo "Branch:   $BRANCH_NAME"
echo "Database: $DATABASE_NAME"

create-project is long-running; the CLI waits for it to finish by default. If it reports already exists:

• Prefer picking a different PROJECT_ID (e.g. append a short suffix) and re-export BRANCH_NAME / DATABASE_NAME from the new id. Lakebase projects can hold data that other apps and pipelines depend on, so do not run databricks postgres delete-project on an existing project without explicit confirmation from the user that nothing else uses it.
• Eventual-consistency exception: if you just deleted a project with this id in the same session and databricks postgres list-projects no longer shows it, wait 30–60s and retry create-project — the control plane is briefly inconsistent after deletion.

RAG Chat App

This template demonstrates a Retrieval-Augmented Generation chat app built on Databricks: a user question is embedded, similar documents are retrieved from a pgvector store in Lakebase Postgres, and the retrieved context is injected into a Model Serving call that streams the answer back. Conversations and sources are persisted per chat in Lakebase.

Data Flow

All retrieval and chat state live in Lakebase Postgres; generation uses AI Gateway:

1. Seeding pulls a handful of Wikipedia articles on startup, chunks them by paragraph, embeds each chunk through the AI Gateway embeddings endpoint (databricks-gte-large-en by default), and writes rows into rag.documents with a vector(1024) column.
2. User turns are embedded with the same endpoint. The server runs a pgvector cosine-similarity search to retrieve the top-k matching chunks.
3. Context injection: the retrieved chunks are prepended as a system message before the user's conversation history is sent to the chat completion endpoint (databricks-gpt-5-4-mini by default) via AI Gateway.
4. Streaming: streamText streams tokens back to the client while an onFinish callback appends the assistant turn to Lakebase.
5. Chat history: every user and assistant turn is persisted in chat.messages, keyed by chat_id, so conversations can be resumed.

Template Approach

Unlike the other templates, this template is designed to be consumed via databricks apps init, not git clone. The init flow:

• Prompts for the Lakebase Postgres branch and database resource names.
• Auto-resolves PGHOST, PGDATABASE, and LAKEBASE_ENDPOINT into your local .env by calling the Lakebase APIs.
• Writes DATABRICKS_CONFIG_PROFILE or DATABRICKS_HOST based on your Databricks CLI configuration.
• Drops you into a ready-to-run project directory named by --name.

This validates the AppKit templates system as a way to ship DevHub templates — see appkit.plugins.json and .env.tmpl in the template for how it works.

What to Adapt

Setup and provisioning are documented in the repository's template/README.md.

To make this template your own:

• Lakebase: Point the bundle at your own Lakebase project, branch, and database (prompted at init time).
• Model Serving endpoint: Override DATABRICKS_ENDPOINT for a different chat model (e.g. databricks-claude-sonnet-4).
• Embeddings endpoint: Override DATABRICKS_EMBEDDING_ENDPOINT if you want a different embedding model. Make sure the vector(N) dimension in server/lib/rag-store.ts matches.
• Seed data: Replace the Wikipedia article list in server/lib/seed-data.ts with your own corpus. The chunking function splits on paragraph boundaries — adapt if your source has different structure.
• Retrieval: The default top-k is 5 and the similarity metric is cosine. Tune in retrieveSimilar().

Deployment

4. Install and deploy

databricks apps init already wrote .env with the resolved Lakebase connection details. For a deploy-only flow you can go straight to deploy — DATABRICKS_WORKSPACE_ID and the Lakebase variables are auto-injected into the deployed runtime from app.yaml and the bound postgres resource.

cd rag-chat-app
npm install
npm run deploy

npm run deploy wraps three steps: hydrate the bundle variable overrides from .env + the Lakebase Postgres API (scripts/sync-bundle-vars.mjs), databricks bundle deploy (creates the Databricks app on first run), and databricks bundle run app (starts it and prints the URL).

Optional — run locally before deploying

Local npm run dev needs DATABRICKS_WORKSPACE_ID (the numeric id used to build the AI Gateway URL) in .env. In the deployed app this is auto-injected; locally you have to fetch and patch it yourself:

WORKSPACE_ID=$(databricks api get /api/2.1/unity-catalog/current-metastore-assignment \
  | python3 -c "import json,sys;print(json.load(sys.stdin)['workspace_id'])")
sed -i.bak "s/^DATABRICKS_WORKSPACE_ID=.*/DATABRICKS_WORKSPACE_ID=$WORKSPACE_ID/" .env && rm .env.bak

npm run dev

(Optionally override DATABRICKS_ENDPOINT / DATABRICKS_EMBEDDING_ENDPOINT in .env if you want different chat / embeddings endpoints — also applies to deploy via app.yaml.)
